TE1 Monocular

The TE1 Monocular features a 1.0 inch 720p AMOLED eyepiece that displays video from any Tactical Electronics camera. While streaming video, the TE1 Monocular can remotely adjust the selected camera’s LEDs and camera views. Stream video over Wi-Fi or over hardwire connection.

The TE1 Monocular features a rugged, locking, Tactical Accessory Port (TAP) that provides USB 2.0, 100Mbps Ethernet, and 12VDC power in.  The USB and Ethernet interfaces can be used to stream video from TE Cameras or MANET radios.

This compact monitor can be mounted to a helmet using the industry standard Wilcox mount.

  • 1.0 inch 720p AMOLED Eyepiece
  • Remote control of connected camera’s LED illumination and selected camera view
  • Tactical Accessory Port provides USB 2.0, 100Mbps Ethernet, and 12VDC power input
  • 5GHz Wi-Fi for wireless video streaming and control
  • Powered by two CR123A batteries or the Tactical Accessory Port (TAP)

Wireless Video:
Real-time video is transmitted across an encrypted 5GHz wireless channel, the video stream is received and displayed on Tactical Electronics’ monitors.

Tactical Accessory Port (TAP):
The hardwire Tactical Accessory Port (TAP) provides a ruggedized friction-locking, breakaway connector with USB 2.0, 100 Mbps Ethernet, and 12VDC power input. The TAP receives hardwired video from the camera source and forwards the video stream onto MANET radios and other tactical radio networks for long-range distribution.

Two CR123 batteries or external battery via the Tactical Accessory Port (TAP)
